Degassing Units

Degassing Units (Mud Degassers) – Sales

High-Performance Vacuum Degassing Units for Drilling Fluid (Mud) Gas Removal and Well Control Operations

Driscoil Equipment Limited supplies premium Vacuum Degassing Units (VDUs) for sale, engineered to efficiently remove entrained and dissolved gases from drilling fluids (drilling mud) during onshore, offshore, geothermal, HDD (Horizontal Directional Drilling), and mining operations. Vacuum degassers are an essential component of the drilling fluid solids control system, helping restore mud density, improve drilling efficiency, and reduce the risk of gas kicks and blowouts.

Installed immediately downstream of the shale shaker and mud/gas separator, the vacuum degasser uses negative pressure to separate gas from drilling fluids before the mud proceeds to desanders, desilters, and decanter centrifuges. This process significantly enhances drilling fluid performance and contributes to safe and stable well control.

Applications

Our Vacuum Degassing Units are suitable for:

Onshore Oil & Gas Drilling

Offshore Drilling Rigs

Jack-Up Rigs

Semi-Submersible Rigs

Drillships

Geothermal Drilling

Horizontal Directional Drilling (HDD)

Mining Operations

Water Well Drilling

Coal Bed Methane (CBM) Drilling

Shale Gas Development

Exploration and Production Wells

Operating Principle

A vacuum degassing unit creates a controlled vacuum inside a sealed vessel, causing dissolved and entrained gases within the drilling mud to expand and separate from the fluid. The gas is safely vented while the degassed drilling fluid is discharged back into the mud system for continued circulation.

This process restores drilling mud density, stabilizes viscosity, improves hydrostatic pressure, and enhances overall well control performance. Vacuum degassers are capable of removing more than 95% of entrained gas from drilling fluids under typical operating conditions.

Technical Specifications

Processing Capacity

Available models include:

120 m³/hr

180 m³/hr

240 m³/hr

270 m³/hr

300 m³/hr

360 m³/hr

Custom capacities available

Degassing Efficiency

≥95%

Vacuum Performance

Vacuum Degree: 300–550 mmHg

Negative Pressure: -0.03 to -0.045 MPa

Mud Properties

Suitable for drilling fluids with mud weights up to approximately 2.5 g/cm³.

Drive System

Main Motor:

15 kW

22 kW

30 kW

37 kW

Vacuum Pump:

2.2 kW

4 kW

5.5 kW

11 kW

Electrical Supply

380V

400V

415V

440V

460V

480V

50 Hz / 60 Hz

Three-Phase

Construction Materials

Carbon Steel

ASTM A36 Steel

Q345 Structural Steel

Stainless Steel (Optional)

H₂S Resistant Materials (Optional)

Surface Protection

Epoxy Coating

Marine Paint System

Offshore Corrosion Protection

Hot-Dip Galvanized Components (Optional)

Major Components

Vacuum Vessel

Vacuum Pump

Explosion-Proof Electric Motor

Gas Separation Chamber

Degassing Rotor

Impeller Assembly

Suction Line

Discharge Line

Automatic Float Level Control

Vacuum Gauge

Pressure Gauge

Safety Relief Valve

Electrical Control Panel

Structural Base Frame

Operating Features

High Degassing Efficiency

Continuous Operation

Self-Priming Design

Compact Footprint

Low Energy Consumption

Minimal Maintenance

Low Operating Noise

Heavy-Duty Industrial Construction

Automatic Mud Level Control

High Reliability

Performance Benefits

Removes entrained gas from drilling mud

Restores drilling fluid density

Improves drilling efficiency

Stabilizes mud rheology

Enhances hydrostatic pressure control

Reduces risk of gas kicks

Supports blowout prevention

Extends drilling fluid service life

Improves downstream solids control equipment performance

Safety Features

Explosion-Proof Electric Motors

Emergency Stop System

Pressure Relief Valve

Overload Protection

Automatic Vacuum Protection

Grounding System

Hazardous Area Electrical Components

Emergency Isolation Switch

Compliance Standards

Available units are manufactured to comply with applicable international standards, including:

API RP 13C – Drilling Fluid Processing Equipment

API Q1 – Quality Management Systems

API Spec 8C (where applicable)

ISO 9001

ATEX Certified Components (Optional)

IECEx Hazardous Area Standards

NACE MR0175 / ISO 15156 (Sour Service)

CE Certification (where applicable)

Inspection & Testing

All Vacuum Degassing Units are available for inspection before purchase.

Inspection services include:

Visual Inspection

Mechanical Integrity Inspection

Vacuum Performance Test

Motor Function Test

Electrical Insulation Test

Rotation Verification

Structural Inspection

Vibration Analysis

Performance Verification

Factory Acceptance Test (FAT)

Site Acceptance Test (SAT)

Inspection fees are determined based on equipment location, equipment value, inspection scope, and logistics requirements.

Optional Accessories

Mud Gas Separator

Shale Shaker

Desander

Desilter

Mud Cleaner

Decanter Centrifuge

Mud Agitator

Centrifugal Pumps

Mud Tanks

Mixing Hopper

Control Panels

Spare Parts Package

Available Brands

Subject to availability:

NOV (National Oilwell Varco)

Derrick Corporation

GN Solids Control

KOSUN

TR Solids Control

Brandt

Xi'an TianRui

Jereh

Brightway

Scomi Equipment

Derrick Equipment

TSC Group

Why Choose Driscoil Equipment Limited?

Driscoil Equipment Limited supplies reliable Vacuum Degassing Units from reputable manufacturers and equipment owners to support safe, efficient, and uninterrupted drilling operations. Our services include equipment sourcing, technical evaluation, inspection coordination, logistics support, and after-sales assistance. Whether for onshore exploration, offshore drilling campaigns, or geothermal projects, we provide high-performance degassing systems that improve drilling fluid quality, strengthen well control, and help maximize operational efficiency.
