Shale Shaker

A Shale Shaker is a primary solids-control device used in drilling-fluid processing systems to separate drilled cuttings and other unwanted solid particles from circulating drilling mud.

The shaker uses vibrating screen decks to process drilling fluid as it enters the unit. The liquid phase passes through the screen openings for further treatment, while larger drilled solids are conveyed across the screen and discharged.

The unit shown is a heavy-duty industrial shale shaker configuration, featuring multiple screen decks, vibration/exciter motors, springs, feed manifolds and a skid-mounted frame.

Driscoil Equipment can source and supply shale shakers for sale and lease, subject to the required drilling-fluid capacity, screen configuration and operating conditions.

Technical Specifications

Specification Typical Configuration

Equipment Type Shale Shaker / Vibrating Solids-Control Screen

Primary Function Separation of drilled solids from drilling fluid

Application Oil & Gas Drilling / Solids Control

Operation Vibratory screening

Screen Decks Single or multiple deck configurations

Screen Type Replaceable shaker screens

Screen Mesh Various API mesh/cut-point configurations

Vibration System Electric or mechanical exciter system

Exciter Motors Dual or multiple motor configuration depending on model

Feed System Manifold/distribution feed system

Discharge Solids discharge conveyor/channel

Frame Heavy-duty fabricated steel skid

Springs Heavy-duty vibration isolation springs

Control Local electrical control panel / customer-specified control system

Construction Industrial-grade steel

Fluid Compatibility Water-based and oil-based drilling fluids, subject to manufacturer specification

Installation Rig-mounted / skid-mounted

Operation Onshore & offshore drilling applications

Screen Replacement Modular/replaceable screen panels

Capacity Model and drilling-fluid properties dependent

Cut Point Screen/API designation dependent

Power Requirement Model dependent

Availability For Sale & Lease
